Push/Pull Toggle Clamp – CL-100-LSPC Series with Safety Lock (300 lbs)

Push/Pull Toggle Clamp – CL-100-LSPC Series with Safety Lock (300 lbs)

$76.81


Brand: Carr Lane

Push/Pull Toggle Clamp – CL-100-LSPC Series with Safety Lock (300 lbs)

SKU: CL-100-LSPC Category: Tag:

Description

CL-100-LSPC Tapped PlungerSafety-lock version of our CL-100-SPC toggle clamp. The integral safety lock automatically engages when the clamp is closed, then remains locked until manually disengaged by pressing the lever before opening. This prevents the clamp from being accidentally opened by bumping the handle. Please note, the safety lock functions only in extended position (push), not in retracted position (pull). Tiny yet extremely powerful plunger clamp with a forged steel base. Requires very little mounting space due to its narrow base and compact low profile. 5/8″ plunger travel. Plunger is tapped to accept any 1/4-20 spindle (M6 in metric). Available in in steel or stainless steel. 300 lbs holding capacity.

Additional information

Product Type

Maximum Holding Capacity

300 lb
Plunger Travel

5/8 in
Plunger Thread

1/4 in – 20
Material

1215 Steel (Clamp Body);1008 Steel (Clamp Body);1010 Steel (Clamp Body);1018 Steel (Clamp Body);400 Stainless (Rivets);Vinyl (Handle);Forged Steel (Base);300 Stainless (Clamp Body)
Handle Material

Vinyl
Finish

Zinc Plated Clear Chromate (Clamp Body);Zinc Plated Chromate (Base)
Mounting Type

Flanged
Thread Size

1/4 in – 20
Standards Met

DFARS;RoHS Compliant
